รายละเอียดสินค้า:
การชำระเงิน:
|
| Category: | Travel Motor | Machine model: | EC460C EC460CHR EC480D EC700B |
|---|---|---|---|
| Application: | Excavator Wheel Loader | Product name: | Case |
| Part number: | VOE14535036 14535036 | Packing: | Standard Export Carton |
| เน้น: | Excavator travel motor case,EC460C excavator spare parts,EC480D travel motor fitting |
||
| Name | Case |
| Parts No | VOE14535036 14535036 |
| Machine Model | EC460C EC460CHR EC480D EC480DHR EC480EHR EC700B |
| Category | Travel Motor |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
Generally speaking, if it is an engine - related case, it may be used to house and protect engine components, play a role in supporting and positioning, and ensure the normal operation of the engine. If it is a transfer - case - related case, it is responsible for housing the internal gears, shafts, and other components of the transfer case, and cooperating with the transfer - case assembly to realize the power distribution function of the four - wheel - drive or all - wheel - drive system.
Heavy EC460C EC460CHR EC480D EC480DHR EC480EHR EC700B EC700BHR EC700C EC700CHR Vo-lvo
| VOE14552706 Case |
| EC140C, EC160C, EC180C, EC210C, EC235C, EC240C, EC290C, EC330C, EC360C, EC360CHR, EC460C, EC460CHR, EC700C, ECR145C, ECR235C, ECR305C, EW140C, EW160C, FB2800C, FBR2800C, FC2121C, FC2421C, FC2924C, FC3... |
| VOE14552711 Case |
| EC140C, EC160C, EC180C, EC210C, EC235C, EC240C, EC290C, EC330C, EC360C, EC360CHR, EC460C, EC460CHR, EC700C, EW140C, EW160C, FB2800C, FBR2800C, FC2121C, FC2421C, FC2924C, FC3329C, PL4608, PL4611 |
| VOE14541742 Case |
| EC460B, EC460C, EC460CHR, EC480D, EC480DHR, EC480EHR, FB2800C, FBR2800C, PL3005D, PL3005E, PL4608, PL4611 |
| VOE14612707 Case |
| EC700C |
| VOE14503262 Case |
| EC135B, EC140B, EC160B, EC180B, EC200B, EC210B, EC240B, EC290B, EC330B, EC360B, EC460B, EC700B, EC700BHR, EW140B, EW145B, EW160B, EW180B, EW200B |
| VOE14670629 Case |
| EC120D, EC140D, EC140E, EC160E, EC170D, EC180E, EC200D, EC210D, EC220E, EC250D, EC250E, EC300D, EC300E, EC350E, EC380E, EC380EHR, EC480E, EC480EHR, EC750D, EC750E, EC950E, EW140E, EW160E, EW180E, EW20... |
| VOE14547262 Case |
| EC290B, EC290C, EC300D, EC300E, EC330B, EC340D, EC350D, EC700C, EC700CHR, FC3329C, PL3005D, PL3005E |
| VOE14609495 Case |
| EC700B, EC700BHR, EC700C, EC700CHR |
| VOE14670628 Case |
| EC140E, EC160E, EC170D, EC180E, EC200D, EC210D, EC220E, EC250D, EC300D, EC350E, EC380EHR, EC480EHR, EC750D, EC950E, EW180E, PL3005E, PL4809D |
| VOE14531598 Case |
| EC700BHR, EC700C, EC700CHR, ECR58, ECR88 |
| VOE14535296 Case |
| EC700B, EC700BHR, EC700C |
| VOE14697554 Case |
| EC140E, EC160E, EC180E, EC220E, EC250E, EC300E, EC350E, EC380E, EC380EHR, EC480EHR, EC750E, EC950E, ECR145E, ECR235E, EW140E, PL3005E, PL4809E |
| VOE16679959 Case |
| ECR25D |
| VOE14566995 Case |
| EC140C, EC140D, EW140E, EW145B |
| RM70917620 Case |
| ABG4361, OMNI V |
| VOE14612708 Case |
| EC120D, EC140D, EC700C, ECR145D, ECR235D |
| VOE14549714 Case |
| EC160C, EC160D, EC160E, EC170D, EC180C, EC180D, EC180E |
| SA7118-30510 Case |
| Volvo.Heavy |
| VOE14635136 Case |
| Volvo.Heavy |
| VOE14569188 Case |
| EC55C, EW60C |
| VOE14536003 Case |
| EC330B, EC360B |
| VOE14569189 Case |
| EC55C, EW60C |
| RM15629785 Case |
| PF161 |
| Pos. | Part No | Qty | Parts name | Comments |
| VOE14522564 | [1] | Travel motor | ||
| 1 | VOE14534991 | [1] | Case | |
| 2 | VOE14534992 | [1] | Plate | |
| 3 | SA8230-34150 | [2] | Seat | |
| 4 | VOE14534995 | [2] | Spring | |
| 5 | VOE14534996 | [2] | Seat | |
| 6 | VOE14534997 | [2] | Cap | |
| 7 | VOE14534998 | [2] | Relief valve | |
| 8 | SA8230-32630 | [2] | O-ring | |
| 9 | SA8230-32380 | [2] | Valve | |
| 10 | VOE983494 | [2] | O-ring | |
| 11 | VOE14534999 | [3] | Valve | |
| 12 | SA8230-33400 | [2] | Spring | |
| 13 | SA8230-34050 | [2] | Plug | |
| 14 | VOE990557 | [2] | O-ring | |
| 15 | SA8230-33430 | [2] | Guide | |
| 16 | SA8230-33940 | [2] | Plug | |
| 17 | VOE14535000 | [2] | Non-return valve | |
| 18 | VOE14535001 | [2] | Spring | |
| 19 | VOE14535002 | [2] | Plug | |
| 20 | VOE983527 | [2] | O-ring | |
| 21 | VOE14535003 | [2] | Valve | |
| 22 | VOE14539093 | [1] | Valve | |
| 23 | SA8230-32350 | [2] | Plug | |
| 24 | VOE983502 | [6] | O-ring | |
| 25 | SA8230-32690 | [2] | Plug | |
| 26 | SA8230-33390 | [2] | Plug | |
| 27 | VOE14535005 | [1] | Shaft | |
| 28 | VOE14535006 | [1] | Block | |
| 29 | VOE14535007 | [1] | Plate | |
| 30 | VOE14535008 | [9] | Piston | |
| 31 | VOE14535009 | [1] | Plate | |
| 32 | VOE14535010 | [1] | Holder | |
| 33 | VOE14535011 | [1] | Plate | |
| 34 | VOE14535012 | [2] | Ball | |
| 35 | VOE14535013 | [2] | Piston | |
| 36 | VOE14535014 | [2] | Spring | |
| 37 | VOE14535015 | [1] | Roller bearing | |
| 38 | VOE14535016 | [1] | Roller bearing | |
| 39 | VOE14535017 | [1] | Collar | |
| 40 | VOE14535018 | [1] | Pin | |
| 41 | VOE14535019 | [9] | Spring | |
| 42 | VOE14535020 | [2] | Plate | |
| 43 | VOE14535021 | [4] | Plate | |
| 44 | VOE14535022 | [3] | Plate | |
| 45 | VOE14535023 | [1] | Piston | |
| 46 | SA8230-34070 | [1] | O-ring | |
| 47 | VOE14535024 | [1] | Ring | |
| 48 | VOE14535025 | [1] | O-ring | |
| 49 | VOE14535026 | [1] | Ring | |
| 50 | VOE14535027 | [10] | Spring | |
| 51 | SA8230-32320 | [4] | Pin | |
| 52 | VOE14535028 | [1] | Seal | |
| 53 | VOE960262 | [1] | O-ring | |
| 54 | SA9511-12010 | [1] | O-ring | |
| 55 | VOE14535029 | [2] | Plug | |
| 56 | VOE983524 | [2] | O-ring | |
| 57 | VOE14535030 | [9] | Bolt | |
| 58 | VOE14535031 | [2] | Plug | |
| 59 | VOE14535032 | [1] | Plate | |
| 600 | VOE14535034 | [1] | Block | Inc. 28,29,30 |
| 700 | VOE14535035 | [1] | Plate | Inc.31,32 |
| 800 | VOE14535036 | [1] | Case | Inc. 1,35,58 |
| 900 | VOE14539094 | [1] | Plate | Inc. 9,11,21,22 |
| 100 | VOE14535033 | [1] | Seal |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Advantage
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
